Flexible LED module
360 view angle
Model(mm): P2，P2.5，P4 ，P6 ，P10
Size（m）: Support customization
Apexls LED cylindrical screen is specially designed for engineering projects, widely used in various science and technology museums, exhibition rooms, hotels and other places，special shape, more attractive to audience.
Hotel advertising, stage rental, large shopping malls, outdoor gymnasiums, concerts, playgrounds, sightseeing areas, etc.
We offer a wide range of standard and custom products to meet your specific needs. Our team of experts will work with you to understand your requirements and design a solution that meets your exact specifications.
Seamless splicing, smooth surface, ensure smooth and super clear display effect. The splicing error between modules can be controlled within ±0.1mm. And both inner and outer arcs can be realized.
The cylindrical led display has a 360-degree screen, which can expand the viewing range of viewers in different directions. The led cylinder offers a unique and captivating way to exhibit your content.
With the high gray and high refresh rate design, the led cylinder screen will display the image without any delay or dragging phenomenon.
| KC Series Cylindrical Led Display | |||||
| Model | P2 | P2.5 | P4 | P6 | P10 |
| Pixel Pitch(mm) | 2 | 2.5 | 4 | 6 | 10 |
| LED Type | SMD1515 | SMD2121 | SMD12121 | SMD2121 | SMD3528 |
| Pixel Density(dots/㎡) | 250000 | 160000 | 62500 | 27777 | 10000 |
| Viewing Distance(m) | 2 | 2.5 | 4 | 6 | 10 |
| Brightness(cd/㎡) | ≥1000 | ≥1000 | ≥1000 | ≥1000 | ≥1000 |
| Avg Power Consumption(W/㎡) | 230 | 230 | 300 | 300 | 112.5 |
| Max Power Consumption(W/㎡) | 500 | 500 | 600 | 600 | 250 |
| Refresh Rate(Hz) | 1,920-3,840 | ||||
| Input Voltage | AC100-240V/50-60Hz | ||||
| Life Span | 100,000 hours | ||||
| Working Temperature | -20°C～60°C | ||||
| Working Humidity(RH) | 10%～90% | ||||
| Gray Scale | 12-16 bit | ||||
